Kątowniki

nierównoramienne

Kątowniki nierównoramienne gorącowalcowane

Typ	b [mm]	a [mm]	g [mm]	masa 1 metra [kg/m]
45x30x4	45	30	4	2,24
45x30x5	45	30	5	2,76
60x40x5	60	40	5	3,76
60x40x6	60	40	6	4,46
60x40x7	60	40	7	5,13
70x45x5	70	45	5	4,34
70x50x6	70	50	6	5,40
70x50x7	70	50	7	6,24
70x50x8	70	50	8	7,06
75x50x6	75	50	6	5,65
75x50x7	75	50	7	6,53
75x50x8	75	50	8	7,39
75x50x9	75	50	9	8,33
80x40x6	80	40	6	5,41
80x40x8	80	40	8	7,07
80x65x6	80	65	6	6,60
80x65x8	80	65	8	8,66
80x65x10	80	65	10	10,70
90x60x6	90	60	6	6,82
90x60x8	90	60	8	8,96
100x50x6	100	50	6	6,85
100x50x8	100	50	8	8,99
100x50x10	100	50	10	11,10
100x65x7	100	65	7	8,77
100x65x8	100	65	8	9,94
100x65x9	100	65	9	11,10
100x65x10	100	65	10	12,30
100x65x12	100	65	12	14,5
100x75x7	100	75	7	9,30
100x75x8	100	75	8	10,60
100x75x9	100	75	9	11,80
110x70x10	110	70	10	13,43
110x70x12	110	70	12	15,91
120x80x8	120	80	8	12,20
120x80x10	120	80	10	15,00
120x80x12	120	80	12	17,80
125x75x8	125	75	8	12,20
125x75x9	125	75	9	13,60
125x75x10	125	75	10	15,00
125x75x12	125	75	12	17,80
130x65x8	130	65	8	11,90
130x65x10	130	65	10	14,60
130x65x12	130	65	12	17,30
130x90x10	130	90	10	16,60
130x90x12	130	90	12	19,70
130x90x14	130	90	14	22,74
140x90x8	140	90	8	14,04
140x90x10	140	90	10	17,37
140x90x12	140	90	12	20,6
140x90x14	140	90	14	23,8
150x75x9	150	75	9	15,30
150x75x10	150	75	10	17,00
150x75x11	150	75	11	18,60
150x75x12	150	75	12	20,2
150x90x10	150	90	10	18,20
150x90x12	150	90	12	22,40
150x100x10	150	100	10	19,00
150x100x11	150	100	11	20,80
150x100x12	150	100	12	22,60
150x100x14	150	100	14	26,10
160x80x10	160	80	10	18,20
160x80x12	160	80	12	21,00
160x80x14	160	80	14	25,00
180x90x10	180	90	10	20,60
180x90x12	180	90	12	24,50
180x90x14	180	90	14	28,30
200x100x10	200	100	10	23,00
200x100x12	200	100	12	27,30
200x100x14	200	100	14	31,60
200x100x16	200	100	16	35,90
250x90x10	250	90	10	26,10
250x90x12	250	90	12	31,10
250x90x14	250	90	14	36,00
250x90x16	250	90	16	40,90
